INTELLIDOX DOCKING MODULE USER MANUAL || DETECTOR OPERATIONS
HONEYWELL PAGE 55 OF 119
Special Considerations for IntelliDoX Ultra, BW Solo, and BW Icon (DX-CP)
Note: IntelliDoX Ultra requires Safety Suite Device Configurator v4.5.x or greater.
Pre-Conditioning of the system is required for calibration of Ultra for NH3. Like a
bump test, it is necessary to flow the gas prior to a successful calibration:
1. Place unit in the dock
2. Select calibration using the IntelliDoX menu
• Pump test once to pre-condition the system – This pump test might result in
a fail.
• Pump test the second time to test device – This pump test shall result in a
pass.
For best performance with reactive gases such as CL2 and NH3 it is recommended to use
short lengths of Teflon lined tubing for the connection between the gas cylinder and the
IntelliDoX.
Note: For BW Ultra NH3 calibration with Intellidox requires a wait period of 15
minutes between calibrations.
Special Considerations for the MaxXT II Detector
Note: Insert the MaxXT II detector in the nest after the detector has started up for
calibration.
Calibration of PID sensor
PID sensors have two calibration options: 3-point and 2-point. This manual section will
detail the necessary steps to perform both calibration types.
3-point calibration for PID sensor:
1. In the Safety Suite Device Configurator tool enable 3-point calibration option for
PID under BW Ultra configuration tab and save this configuration on Ultra
detector.
2. Install multi inlet key in the IntelliDoX and configure 2 inlets for Isobutylene gas in
which one inlet is for span low gas concentration and another is for span high
gas concentration.
3. Place the detector into the IntelliDoX nest and close the lid.
4. After detector recognition IntelliDoX will provide 3 options bump test, calibration
and transfer data-log from my detector.
5. Click on calibration option and apply Isobutylene gas.
6. After successful calibration IntelliDoX will display “calibration passed” with green
color background screen with ICON and on the Ultra detector cal date and cal
status is updated as pass.
NOTE: If only one inlet is configured a missing gas screen will be shown by the
IntelliDoX at unit insertion.
2-point calibration for PID sensor:
1. In the Safety Suite Device Configurator tool disable 3-point calibration option for
PID under BW Ultra configuration tab and save this configuration on Ultra
detector.
2. In the IntelliDoX configure one inlet for Isobutylene gas and place Ultra detector
into the IntelliDoX nest and close the lid.
3. After detector recognition IntelliDoX will provide 3 options bump test, calibration
and transfer data-log from my detector.
4. Click on calibration option and apply Isobutylene gas.
5. After successful calibration IntelliDoX will display “calibration passed” with green
color background screen with ICON and on the Ultra detector cal date and cal
status is updated as pass.
