Honeywell SC Series User Manual

Honeywell Sensing and Control 9
SC 2000, SC2001, SC3004
Rev. G, 008-0608-00
Chapter 4 Chassis Models
4.1 Introduction
The SC Series of Signal Conditioners/Indicators are available in
several different chassis models. In general, each chassis model
operates in an identical fashion and can be ordered with any type
of Input channels, Output channels, or Virtual channels.
Input channels and Output channels are printed circuit boards
that occupy a physical slot inside the instrument’s chassis. 12-
pin connectors are located on the rear panel to connect to each
Input or Output Channel. Each channel in the instrument is identi-
fied by a number (channel 01, channel 02, etc.).
A Virtual channel exists in software only; it does not occupy a
physical slot inside the instrument’s chassis. There is no rear-
panel connector for a Virtual channel. However, a Virtual channel
does require a channel number.
4.2 Specications
Model SC2000 Model SC2001 Model SC3004
GENERAL
# Physical channels 1 to 4 1 to 4 1 to 14
# Virtual channels 8 8 8
Case material Aluminum Aluminum Aluminum
PHYSICAL
Form factor 3/8 DIN suitcase 2U rack
Mounting bench, panel or rack portable rack
DISPLAY
# characters/line 16 16 20
# lines/display 2 2 4
# displays 1 1 1, 2 or 3
Display type Vacuum
Fluorescent
Vacuum
Fluorescent
Vacuum
Fluorescent
ENVIRONMENTAL
Storage temp. -30 °C to 90 °C -30 °C to 90 °C -30 °C to 90 °C
Operating temp. 5 °C to 40 °C 5 °C to 40 °C 5 °C to 40 °C
Relative humidity 80% max. for temperatures up to 31 °C; decreasing linearly to 50% max. at 40 °C
Other indoor use at altitudes up to 2000 m; Pollution Degree 2; Overvoltage Category II
SPECIAL FEATURES
Limits quantity 4 std., 16 max. 4 std., 12 max. 4 std., 16 max.
Digital, isolated control
inputs
4 4 4
POWER
Standard AC powered (au-
tomatic selection)
100 Vac to 230 Vac,
47 Hz to 63Hz
100 Vac to 230 Vac,
47 Hz to 63Hz
100 Vac to 230 Vac,
47 Hz to 63Hz
Optional Vehicle Powered 11 Vdc to 28 Vdc, 20 W 11 Vdc to 28 Vdc, 20 W N/A
Total Excitation Drive 120 mA max. 120 mA max. 400 mA max.
