Honeywell SC Series User Manual

40 Honeywell Sensing and Control
Signal Conditioning, Self Calibrating Digital Indicators
Rev. G, 008-0608-00
11.3 Calibration Procedure
If you are not familiar with operating the instrument in the SETUP
menu mode, see “SETUP Menu mode” on page 7. A listing of all
menu items is given in “Setup Menu Reference” on page 77.
• Step1:Wirethetransducertothechannel’sconnector.
See “Wiring” on page 39 for details.
• Step2:EntertheCALIBRATION TYPE.
You must have the capability to apply either two, three, or
five known displacements to the transducer. The CALIBRA-
TION TYPE menu item allows you to specify how many
known displacements will be applied during calibration.
• Step3:EntertheCALIBRATION DATA.
Consult the Certificate of Calibration for the transducer when
entering information in the CALIBRATION DATA sub-menu.
• Step4:DeterminetheLVDT’selectricalnullpoint,thenphysi-
cally mount it.
The electrical null is the armature position that produces the
least electrical output. Once this point has been determined,
the transducer is physically clamped into position. See
“Electrical Null and Transducer Mounting” on page 45.
• Step5:Performthecalibration.
Using the CALIBRATE menu item starts the calibration pro-
cess. You will be prompted to apply displacements to the
transducer as required.
11.4 Specications
TRANSDUCER INPUT
Transducer type full-bridge, AC/AC-LVDT
Excitation Voltage 3 V RMS @ 5kHz, short circuit pro-
tected
Transducer full-scale
output
0.1 to 15 V RMS @ 3 V RMS excita-
tion
Amplifier gain selection automatic
Calibration type 2-, 3- or 5- point known displace-
ment
A/D converter 24-bit Sigma-Delta
Low-pass filter digital, 24-tap FIR
Resolution see page 41
Frequency response see page 41
AUXILLARY INPUTS
Quantity 2
Type momentary contact closure
Response time < 5 ms
Field-selectable func-
tions
tare on, tare off, peak/valley clear,
peak/valley hold, track hold
ANALOG OUTPUTS
Voltage range (voltage
output channels)
5,±5,10or±10Vdc
Current range (current
output channels)
4 mA to 20 mA
Source any channel’s track, peak, or valley
value
Isolation 500 V
Resolution 13 bits
Frequency response same as input when driven by the
same channel’s tracking data

Honeywell SC Series Specifications

General

Sensing Technology	Electrochemical
Target Gas	CO
Response Time (T90)	Varies by gas and sensor type; refer to datasheet for specific values
Expected Life	Varies by sensor type; refer to datasheet for specific values
Measurement Range	Varies by gas and sensor type; refer to datasheet for specific values
Resolution	Varies by gas and sensor type; refer to datasheet for specific values
Response Time	Varies by gas and sensor type; refer to datasheet for specific values
Battery Life	N/A (typically used with external power source)
Dimensions	Varies by model; refer to datasheet for specific dimensions
Weight	Varies by model
Operating Humidity	15% to 95% RH (non-condensing)
