TR80 - Installation and Operation Guide32
CONFIGURATION OF TR80
3.1 INTRODUCTION
This chapter provides descriptions for all Modbus registers and configuration parameters that
can be used to adopt the TR80 to specific requirements.
The information is provided in tables, showing:
•Modbus register type (Coil / Input / Holding)
•Modbus register address in two schemes (decimal and absolute)
•Modbus register direction (R = Read Only; R/W = Read/Write)
•Unit and scaling for modbus read/writes where necessary
•Configuration parameter number, if it is a parameter that appears on the device config menu.
•Factory default value.
•Most registers and configuration parameters are self-explanatory, but further explanations
are provided for most.
3. 1. 1 Entering the configuration mode
Only installer or authorized service engineer can access this mode. The procedure to configure
parameter is as follows:
1.Long press and together to enter in configuration mode.
The setting icon is displayed on the screen.
2.Enter the Pin. Refer
Entering The Pin section for more details.
Note:Default pin is 4663. Change the defult pin on completion of commissioning. Refere
User access
control and timeouts to change pin
3.Tap to change selected parameter.
Parameter Number keep blinking at the top part of the display and the parameter's value on
the bottom part.
