3. 8. 4 LCD Symbols
Most symbols on the LCD are activated with internal logic depending on current status (occu-
pancy etc). Other symbols can be only activated via Modbus by a master controller, as
explained below.
The alarm symbol is normally activated by internal fault conditions (see
Fault Conditions). The
master controller can override this as above.
3. 8. 5 Text override
If a non-zero value is written to this register, the upper screen area will display the selected
scrolling text. This overrides any other text that might otherwise be displayed.
Register
type
Relative
Address
Absolute
Address
DirNameTypeRange
Default
value
Holding110241103R/W
Window open symbol
Enum
0: off
1: on
2: blink
0
Holding110341104R/W
ECO symbol
Enum
0: off
1: on
2: blink
0
Holding110441105R/W
Alarm symbol
Enum
0: off
1: on
2: blink
3: auto
3
Holding110541106R/W
Day/night symbol
Enum
0: off
1: sun symbol on
2: moon symbol on
3: sun symbol blink
4: moon symbol blink
0
Register
type
Relative
Address
Absolute
Address
DirNameTypeRange
Default
value
Holding110641107R/WText overrideenum
0: none
1: "Fan Off"
2: “Clg/Htg Off”
3: "Window Open"
4: "Condensation"
5: "Fire"
6: "Service required"
0
