Honeywell TR80

35TR80 - Installation and Operation Guide
3.3 COMMUNICATION
3. 3. 1 Port 1 configuration
The TR80 wall module is a Modbus slave on its port 1.
3. 3. 2 Port 2 configuration
Port 2 on the TR80 wall module has two functions. It can act as a repeater between a master
controller and a downstream DALI64 sensor. Secondly, it can send basic light level and scene
commands of the user directly to a DALI64MOD sensor. These two functions do not conflict,
they can be used simultaneously.
*
Baud rate and parity enumerations are same as
Port 1 configuration.
If a DALI64 sensor is connected on port2, the DALI64 device's slave address must be set on
configuration parameter 12.
Register
type
Relative
Address
Absolute
Address
DirName
Config
parameter
TypeRange
Default
value
Holding200242003R/W
Modbus slave
address
4int1-2472
Holding200342004R/WPort 1 baud rate5enum
0: 1200 baud
1: 2400 baud
2: 4800 baud
3: 9600 baud
4: 14400 baud
5: 19200 baud
6: 38400 baud
5
Holding200442005R/WPort 1 parity6enum
0: none
1: odd
2: even
2
Holding200542006R/W
Port 1 number of
stop bits
7int1-21
Register
type
Relative
Address
Absolute
Address
DirName
Config
parameter
Type /
Unit
Range
Default
value
Holding200642007R/WPort 2 baud rate8enum
See port 1
*
5
Holding200742008R/WPort 2 parity9enum
See port 1
*
2
Holding200842009R/W
Port 2 number of
stop bits
10int1-21
Holding200942010R/W
Port 2 Response
Timeout
11msec200-3000500
Holding201042011R/W
DALI64 slave
address
12int
0-247
(0=disabled)
0
