Honeywell TR80 User Manual

68 TR80 - Installation and Operation Guide
List of Blinds configuration Parameters
Config
parameter
number
Name Type/ Unit
Range
(min-Max)
Default Notes
400 Blind Group Count int 0…2 1
401 Blinds position adjust
step size
enum 0: 1%
1 : 2%
2 : 5%
3: 10%
4: 20%
3
402 Blinds angle adjust
step size
enum 0: 1%
1 : 2%
2 : 5%
3: 10%
4: 15%
3
403 Blind group 1 type bitmap Bit0: angle
control (0:
position only,
1:
position+angl
e)
Bit 1: position
direct/
reverse (0:
reverse, 1:
direct)
1 Direct: up button works 0-
>100%
Reverse: up button works
100->0%
404 Blind 1 position min % 0…100% 0
405 Blind 1 position max % 0…100% 100
406 Blind 1 angle min signed int (°) -180°…180° -80°
407 Blind 1 angle max signed int (°) -180°…180° +80°
408 Blind group 2 type bitmap Bit0: angle
control (0:
position only,
1:
position+angl
e)
Bit 1: position
direct/
reverse (0:
reverse, 1:
direct)
1 Direct: up button works 0-
>100%
Reverse: up button works
100->0%
409 Blind 2 position min % 0…100% 0
410 Blind 2 position max % 0…100% 100
411 Blind 2 angle min signed int (°) -180°…180° -80°
412 Blind 2 angle max signed int (°) -180°…180° +80°
