3. 11. 5 Light Group 4 configuration & control
The group 3 configuration parameters are explained in below table. Refer lighting group1 for
explanation.
The group 3 control parameters are explained in below table. Refer lighting group1 for
explanation.
3. 11. 6 Scene definitions for Power Button
Wherever the power button function isto turn lights on/off (see register 2110/2111, config
parameter 108/109), the wall module will need to know what scenes to recall for that purpose.
Set to zero if no such scene is configured on the DALI side. If set to zero, TR80 will send abso-
lute light level commands (0% / 100%) to turn lights off / on.
Register
type
Relative
Address
Absolute
Address
DirName
Config
Parameter
UnitRange
Default
value
Holding231442315R/W
Light Group 4
allow dimming
314enum
0: only on/off
control
1: allow dimming
1
Holding231542316R/W
Light Group 4
min level
315%0…100%1%
Holding 231642317R/W
Light Group 4
max level
316%0…100%100%
Holding231742318R/W
Light Group 4
max Scene No
317int0-164
Register
type
Relative
Address
Absolute
Address
DirNameUnitRange
Default
value
Holding130641307R/WLight Group level feedback%0-100%
32768
(invalid)
Holding130741308R/WLight Group last scene feedbackint0-150
Input30630307R/WLight Group 4 new level%0-100%32767
Input30730308R/WLight Group 4 new sceneint0-1532767
Register
type
Relative
Address
Absolute
Address
DirName
Config
parameter
UnitRange
Default
value
Holding231842319R/WScene For Lights ON318Int-1 - 16-1
Holding231942320R/WScene For Lights OFF319Int-1 - 16-1
