Honeywell TR80 User Manual

TR80 - Installation and Operation Guide 54
3.12 BLINDS CONTROL
TR80 can control up to 2 blinds, curtains or shutters. General blind parameters are as
shown below.
3. 12. 1 Blind Group 1 configuration parameters
Blind type setting detail:
Bit 0 - Angle Control:
0 = up/down positioning only – no slat angle control
1 = up/down positioning + slat angle control
Bit 1 – Position direct/reverse
0: reverse (up is 0%. Up button changes value 100->0%)
1: direct (up is 100%. Up button changes value 0->100%)
Register
type
Relative
Address
Absolute
Address
Dir Name
Config
parameter
Unit Range
Default
value
Holding 2400 42401 R/W Blind Group Count 400 int 0…2 1
Holding 2401 42402 R/W
Blind position
adjustment step size
401 enum
0: 1%
1: 2%
2: 5%
3: 10%
4: 20%
3
Holding 2402 42403 R/W
Blinds angle
adjustment step size
402 enum
0: 1°
1: 2°
2: 5°
3: 10°
4: 15°
5: 20°
6: 25°
7: 30°
8: 40°
9: 50°
3
Register
type
Relative
Address
Absolute
Address
Dir Name
Config
parameter
Unit Range
Default
value
Holding 2403 42404 R/W Blind 1 type 403 bitwise
Bit 0: angle
control
Bit 1: position
direct/reverse
1
Holding 2404 42405 R/W Blind 1 min pos 404 % 0…100% 0%
Holding 2405 42406 R/W Blind 1 max pos 405 % 0…100% 100%
Holding 2406 42407 R/W Blind 1 min angle 406 ° -180°…180° -80°
Holding 2407 42408 R/W Blind 1 max angle 407 ° -180°…180° +80°
