Honeywell TR80

TR80 - Installation and Operation Guide52
3. 11. 3 Light Group 2 configuration & control
The configuration parameter for group 2 are explained in below table. Refer lighting
group1 for explanation.
The group 2 control parameters are explained in below table. Refer lighting group1 for
explanation.
3. 11. 4 Light Group 3 configuration & control
The group 3 configuration parameters are explained in below table. Refer lighting group1
for explanation.
The group 3 control parameters are explained in below table. Refer lighting group1 for
explanation.
Register
type
Relative
Address
Absolute
Address
DirName
Config
Parameter
UnitRange
Default
value
Holding230642307R/W
Light Group 2
allow dimming
306enum
0: only on/off
control
1: allow dimming
1
Holding230742308R/W
Light Group 2
min level
307%0…100%1%
Holding 230842309R/W
Light Group 2
max level
308%0…100%100%
Holding230942310R/W
Light Group 2
max Scene No
309int0-164
Register
type
Relative
Address
Absolute
Address
DirNameUnitRange
Default
value
Holding130241303R/WLight Group level feedback%0-100%
32768
(invalid)
Holding130341304R/WLight Group last scene feedbackint0-150
Input30230303R/WLight Group 2 new level%0-100%32767
Input30330304R/WLight Group 2 new sceneint0-1532767
Register
type
Relative
Address
Absolute
Address
DirName
Config
Parameter
UnitRange
Default
value
Holding231042311R/WLight Group 3 allow dimming310
enu
m
0: only on/off
control
1: allow dimming
1
Holding231142312R/WLight Group 3 min level311%0…100%1%
Holding 231242313R/WLight Group 3 max level312%0…100%100%
Holding231342314R/WLight Group 3 max Scene No313int0-164
Register
type
Relative
Address
Absolute
Address
DirNameUnitRange
Default
value
Holding130441305R/WLight Group level feedback%0-100%
32768
(invalid)
Holding130541306R/WLight Group last scene feedbackint0-150
Input30430305R/WLight Group 3 new level%0-100%32767
Input30530306R/WLight Group 3 new sceneint0-1532767
