Setpoint Rate/Ramp/Soak Program Operation
5/00 UDC3300 Expanded Model: DC330E User Manual 91
Function Press Result
Keyboard Reset
LOWER
DISPLAY
until you see
Lower Display: ToBEGN
Press
▲ key to reset program to beginning at Hold state.
Viewing the
Present Ramp or
Soak Segment
Number and Time
LOWER
DISPLAY
until you see
Upper Display: "R" and the PV value
Lower Display: Ramp segments: # RA XX.XX
Soak segments: # SK XX.XX
# indicates the segment number (Ramp–odd only, Soak–
even only)
XX.XX Ramp Time – Hours.Minutes
Ramp Rate – EU/MIN or EU/HR
Soak Time – Hours.Minutes
Viewing the
Number of Cycles
Left in the
Program
LOWER
DISPLAY
until you see
Upper Display: "R" and the PV value
Lower Display: RECYC XX
Number of cycles remaining in the setpoint program.
XX = 0 to 99
End Program When the final segment is completed, the "R" in the upper
display either changes to "H" (if configured for HOLD
state) or disappears (if configured for disable of setpoint
programming).
The controller operates at the last setpoint in the program
in automatic or will be in manual mode at the failsafe
output.
Disable Program See Section 3.5 for details.
