Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 47
3.16 Alarms Set Up Group
Table 3-15 Alarms Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
A1S1 VAL
Alarm 1, Setpoint 1 Value Value in Engineering Units 90
A1S2 VAL
Alarm 1, Setpoint 2 Value Value in Engineering Units 10
A2S1 VAL
Alarm 2, Setpoint 1 Value Value in Engineering Units 95
A2S2 VAL
Alarm 2, Setpoint 2 Value Value in Engineering Units 5
A1S1TYPE
Alarm 1, Setpoint 1 Type NONE
INP 1
INP 2
INP3
PV (Loop 1 Process Variable)
DEV (Loop 1 Deviation)
OUTPUT (Loop 1 Output)
SHED (Both Loops)
EV ON (Event On – SP
Program)
EV OFF (Event Off – SP
Program)
MANUAL (Loop 1)
REM SP (Loop 1 Remote
Setpoint)
F SAFE (Loop 1 Failsafe)
PVRATE (Loop 1 PV Rate of
Change)
PV 2 (Loop 2 Process Variable)
DEV 2 (Loop 2 Deviation)
OUT 2 (Loop 2 Output)
MAN 2 (Loop 2 Manual )
RSP 2 (Loop 2 Remote
Setpoint)
F SAF2 (Loop 2 Failsafe)
PVRAT2 (Loop 2 PV Rate of
Change)
BREAK
BREAK2
TOTAL
continued
NONE
