Setpoint Rate/Ramp/Soak Program Operation
5/00 UDC3300 Expanded Model: DC330E User Manual 59
Set Tuning Constant Values for Each Set
There are specific tuning constants that must be set for each set. The procedure
below shows you how to access these constants and change their value.
Table 4-7 Procedure for Setting Tuning Constant Values
Step Operation Press Action
1
Select
Tuning Set
Up Group
SET UP
until you see TUNING in the Lower Display
FUNCTION
LOOP 1/2
to successively display the available constants in the
Lower Display. The value is displayed in the Upper
Display
2
Select the
tuning
constants
▲ or ▼
To change the value of any of the above listed prompts
in the lower display.
Switch Between Two Sets via the Keyboard (Without Automatic Switchover)
This procedure is operational only if 2 PID SETS was configured at the Control Set
Up group.
Table 4-8 Procedure for Switching PID SETS from the Keyboard
Step Operation Press Action
1
Access the
PID set
display
LOWER
DISPLAY
until you see the PV value displayed in the Upper
Display and the PIDSETx in the Lower Display.
▲ or ▼
to change PID SET 1 to PID SET 2 or vice versa.
You can use Accutune on each set.
