Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 51
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
COUNTER 1
continued
Counter 1
continued
OUT1*1K (Output 1 Relay x 1000)
OUT2*1K (Output 2 Relay x 1000)
GSOAK (Guaranteed Soak)
PWRCYC (Power Cycle)
PV_RNG (Loop 1 PV Range)
FAILSF (Loop 1 Failsafe)
TUNE (Loop 1 Tune)
MAN2 (Loop 2 Manual)
PVRNG2 (Loop 2 PV Range)
FSF2 (Loop 2 Failsafe)
TUNE2 (Loop 2 Tune)
COUNTS 1
Number of Counts 1 Read Only
COUNTER 2
Counter 2 Same as Counter 1 DISABL
COUNTS 2
Number of Counts 2 Read Only
COUNTER 3
Counter 3 Same as Counter 1 DISABL
COUNTS 3
Number of Counts 3 Read Only
PASSWORD
Password 0-9999 0
RESTYPE
Reset Type NONE (No value will be reset)
TIMER1 (Timer 1 will be reset)
TIMER2 (Timer 2 wil be reset)
TIMER3 (Timer 3 will be reset)
ALLTM (All timers will be reset)
COUNT1 (Counter 1 will be reset)
COUNT2 (Counter 2 will be reset)
COUNT3 (Counter 3 will be reset)
ALL CO (All counters reset)
ALL TC (All timers/counters reset)
NONE
3.20 Status Group
The prompts used hare are read only. They are used to determine the reason for a
controller failure. Refer to Section 9 – Troubleshooting in manual #51-52-25-55 for
complete information.
