Honeywell UDC3300 User Manual

Configuration
50 UDC3300 Expanded Model: DC330E User Manual 5/00
3.18 Calibration Group
The prompts used here are for field calibration purposes. Refer to Section 7 -
Calibration in manual #51-52-25-55 for complete information and instructions.
3.19 Maintenance Parameters Set Up Group
Table 3-17 Maintenance Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
Time 1
Timer 1 DISABL
LASTR (Last Reset)
AL1SP1 (Alarm 1 Setpoint 1)
AL1SP2 (Alarm 1 Setpoint 2)
AL2SP1 (Alarm 2 Setpoint 1)
AL2SP2 (Alarm 2 Setpoint 2)
MANUAL (Loop 1 Manual)
GSOAK (Guaranteed Soak)
SOOTING (Sooting State)
DIGIN1 (Digital Input 1)
DIGIN2 (Digital Input 2)
MAN2 (Loop 2 Manual)
DISABL
HRS.MIN1
or
DAYS.HRS1
Elapsed Time 1 Read Only
TIME 2
Timer 2 Same as TIME 1 Disabl
HRS.MIN2
or
DAYS.HRS2
Elapsed Time 2 Read Only
TIME 3
Timer 3 Same as TIME 1 Disabl
HRS.MIN3
or
DAYS.HRS3
Elapsed Time 3 Read Only
COUNTER 1
Counter 1 DISABL
MANUAL (Loop 1 Manual)
AL1SP1 (Alarm 1 Setpoint 1)
AL1SP2 (Alarm 1 Setpoint 2)
AL2SP1 (Alarm 2 Setpoint 1)
AL2SP2 (Alarm 2 Setpoint 2)
DIGIN1 (Digital Input 1)
DIGIN2 (Digital Input 2)
DISABL
