Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 25
3.4 Loop 2 Tuning Parameters Set Up Group
Table 3-3 Loop 2 Tuning Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
PROPBD3
or
GAIN 3
Proportional Band 3
or
Gain 3
0.1 to 9999
0.001 to 1000
- -
1.000
or
GAINVALn
or
Gain Value being used by
Gain Scheduling when
enabled
Read Only - -
RATE3MIN
Rate 3 in minutes 0.00 to 10.00 minutes 0.00
RSET3MIN
or
RSET3RPM
Reset 3 in minutes/repeat
or
Reset 3 in repeats/minute
0.02 to 50.00 1.00
- -
MANRSET3
Manual Reset 3 –100 to 100% Output 0.0
PROPBD4
or
GAIN 4
Proportional Band 4
or
Gain 4
0.1 to 9999%
0.001 to 1000
- -
1.000
RATE4MIN
Rate 4 in minutes 0.00 to 10.00 minutes 0.00
RSET4MIN
or
RSET4RPM
Reset 4 in minutes/repeat
or
Reset 4 in repeats/minute
0.02 to 50.00 1.00
- -
CYC3 SEC
or
CYC3 SX3
Cycle Time 3 (Heat) 1 to 120 20
CYC4 SEC
or
CYC4 SX3
Cycle Time 4 (Cool) 1 to 120 20
