Configuration
22 UDC3300 Expanded Model: DC330E User Manual 5/00
3.2 Configuration Procedure
Each of the Set Up groups and their functions are pre-configured at the factory. The
factory settings are shown in Table 3-2 through Table 3-16. Follow the procedure in
Table 3-1 if you want to make changes to any of these selections or values. Record
your selections on the Configuration Record Sheet found in Appendix C.
Table 3-1 Configuration Procedure
Step Operation Press Result
1
Select Set Up
mode
SET UP
Upper Display: SET UP
Lower Display: TUNING (This is the first Set Up
group title.)
2
Select any Set
Up group
SET UP
Sequentially displays the other Set Up group titles.
You can also use the [▲] [▼] keys to scan the Set
Up groups in both directions. Stop at the Set Up
group title that describes the group of parameters
you want to configure. Then proceed to the next
step.
3
Select a Function
parameter
FUNCTION
Upper Display: Shows the current value or
selection for the first Function prompt of the
selected Set Up group.
Lower Display: Shows the first Function prompt
within that Set Up group.
Sequentially displays the other function prompts of
the selected Set Up group. Stop at the function
prompt that you want to change, then proceed to
the next step.
4
Change the value
or selection
▲ or ▼
Increments or decrements the value or selection
that appears for the selected function.
If the display flashes, you are trying to make an
unacceptable entry.
5
Enter the value
or selection
FUNCTION
or
SET UP
This key selects another Function prompt.
This key selects another Set Up group.
The value or selection you have made will be
entered into memory after another key is pressed.
6
Exit
Configuration
LOWER
DISPLAY
Exits configuration mode and returns the controller
to the same state it was in immediately preceding
entry into the Set Up mode. It stores any changes
you have made.
