Honeywell UDC3300 User Manual

Setpoint Rate/Ramp/Soak Program Operation
54 UDC3300 Expanded Model: DC330E User Manual 5/00
Table 4-1 Lower Display Key Parameter Prompts
Indication Description
OUT
OUTPUT #1—Output value is percent; for Three Position Step control, this is
an estimated motor position when no slidewire exists.
OT2
OUTPUT #2—Appears only if 2-loop or Cascade control is configured.
SP
LOCAL SETPOINT #1—Also current setpoint when using SP Ramp.
2SP
LOCAL SETPOINT #2
3SP
LOCAL SETPOINT #3
RSP
REMOTE SETPOINT
1IN
INPUT 1—Used only with combinational input algorithms.
2IN
INPUT 2
3IN
INPUT 3
POS
SLIDEWIRE POSITION—Used only with TPSC.
CSP
COMPUTER SETPOINT—When SP is in override.
DEV
DEVIATION—Maximum negative display is –999.9.
PIDSETX TUNING PARAMETER SET 1—Selected set for single loop or primary loop
configuration where X is either 1 or 2.
2PIDSETX TUNING PARAMETER SET 2—Selected set for secondary loop configuration
where X is either 1 or 2.
ET XX.XX
ELAPSED TIME—Time that has elapsed on timer in Hours.Minutes.
TR XX.XX
TIME REMAINING—Time that remains on timer in Hours.Minutes
RAMPXXXM
SETPOINT RAMP TIME—Time remaining in the setpoint ramp in minutes.
O SK XXXX
Soak # and TIME REMAINING IN SOAK
1PV
PROCESS VARIABLE 1—For Cascade or 2-loop applications.
2PV
PROCESS VARIABLE 2—For Cascade or 2-loop applications.
AUX
AUXILIARY OUTPUT—Displayed only when Loop 2 is not used, or when Loop
2 is Time Simplex and Loop 1 is not Current Duplex.
OC1
CHARACTERIZED OUTPUT 1—Displayed if Loop 1 output is characterized.
OC2
CHARACTERIZED OUTPUT 2—Displayed if Loop 2 output is characterized.
SPn
SP RATE SETPOINT—Current setpoint for setpoint rate applications
6LJPD
CURRENT TOTALIZATION VALUE—Displays the total flow volume being
measured.
BIA
BIAS—Displays the manual reset value for algorithm PD+MR.
TUNE OFF
LIMIT CYCLE TUNING NOT RUNNING—Appears when Accutune is disabled.
TUNE RUN
LIMIT CYCLE TUNING RUNNING—Appears when Accutune is enabled.
ToBEGIN
RESET SP PROGRAM TO BEGINNING OF FIRST SEGMENT
OTI
OUTPUT OVERRIDE (2 PID LOOPS ONLY)—Appears when internal Loop 1
Output value is displayed. This represents the internal output 1 value before
override.
