Honeywell UDC3300 User Manual

Configuration
36 UDC3300 Expanded Model: DC330E User Manual 5/00
3.9 Input 1 Parameters Set Up Group
Table 3-8 Input 1 Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
IN1 TYPE
Input 1 Actuation Type
For Input Range
Minimum and Maximum
see Appendix E
DISABL W TC H
B TC W TC L
E TC H 100 PT
E TC L 100 LO
J TC H 200 PT
J TC L 500 PT
K TC H RAD RH
K TC L RAD RI
NNM H 0-20mA
NNM L 4-20mA
NM90 H 0-10mV
NM90 L 0-50mV
NIC TC 0-5 V
R TC 1-5 V
S TC 0-10 V
T TC H CARBON
T TC L OXYGEN
0-10mV
XMITTER1
Transmitter
Characterization
B TC S TC
E TC H T TC H
E TC L T TC L
J TC H W TC H
J TC L W TC L
K TC H 100 PT
K TC L 100 LO
NNM H 200 PT
NNM L 500 PT
NM90 H RAD RH
NM90 L RAD RI
NIC TC LINEAR
R TC SQROOT
ANALYT
LINEAR
ANALYTIC
Analytic Selections
XMITTER1 must be set to
ANALYT for this prompt to
appear
NONE
PH
ORP Mv (Millivolts)
CONDms (Milli Siemens)
CONDus (Micro Siemens)
RSTVM^ (Megaohms)
TDS PPm (Parts per Million)
TDS PPb (Parts per Billion)
CONCPt (Parts per Thousand)
DO PPm (Parts per Million)
DO PPb (Parts per Billion)
NONE
