Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 45
3.15 Communications Set Up Group
If your controller does not have this option, the prompts will not appear.
Table 3-14 Communications Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
ComSTATE
Communications Option
State
DISABL MODBUS
MB3K RS422
DISABL
Com ADDR
Communications Station
Address
1 to 99 0
ComADDR2
Loop 2 Communications
Station Address
1 to 99
When ComSTATE = MODBUS,
ComADDR2 = Com ADDR
0
SHED ENAB
Shed Enable DISABL
ENABL
DISABL
SHEDTIME
Shed Time 0 to 255 sample periods
(1 sample period = 0.666 seconds)
0 = No Shed
0
PARITY
Parity NONE
ODD
EVEN
Fixed at NONE when ComSTATE =
MODBUS
ODD
BAUD
Baud Rate 2400
4800
9600
19200
2400
DUPLEX
Duplex Operation HALF
FULL
• When ComSTATE = MODBUS,
this selection is fixed at HALF.
• When the RS422/485/Auxiliary
output option board is installed,
this selection is fixed at HALF.
HALF
