Honeywell UDC3300 User Manual

Configuration
46 UDC3300 Expanded Model: DC330E User Manual 5/00
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
WS FLOAT
Word Swap Order FP B Floating Point big endian
FP BB Floating Point big endian
with byte-swapped
FP L Floating Point little endian
FP LB Floating Point little endian
with Byte-swapped
TX DELAY
Transmission Delay 1 to 500 milliseconds 1
SHEDMODE
Shed Controller Mode
and Output Level
LAST
TO MAN
FSAFE
ToAUTO
LAST
SHEDSP
Shed Setpoint Recall TO LSP
TO CSP
TO LSP
UNITS
Communication Units PERCNT
ENG
PERCNT
CSP RATO
Loop 1 Computer
Setpoint Ratio
–20.0 to 20.0 1.0
CSP BIAS
Loop 1 Computer
Setpoint Bias
–999. to 9999.
(in engineering units)
0
CSP2RATO
Loop 2 or Cascade
Computer Setpoint Ratio
–20.0 to 20.0 1.0
CSP2BIAS
Loop 2 or Cascade
Computer Setpoint Bias
–999. to 9999.
(in engineering units)
0
LOOPBACK
Local Loop Back DISABL
ENABLE
DISABL
