Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 19
3. Configuration
3.1 Overview
The controller is pre-configured at the factory for typical controller settings for a
heating process except the input type and output algorithm must be configured to
match your process. The controller must also be tuned. See Section 4.3.
To assist you in the configuration process, there are prompts that appear in the
upper and lower displays. These prompts let you know what group of configuration
data (Set Up prompts) you are working with and also, the specific parameters
(Function prompts) associated with each group.
Figure 3-1 shows you an overview of the prompt hierarchy. As you will see, the
configuration data is divided into 15 main Set Up groups plus prompts for calibration
and prompts that show the status of the continuous background tests that are being
performed.
Figure 3-1 Prompt Hierarchy
Set Up Group Function Prompts
TUNING
PROP BD
or GAIN
GAINVALn RATE MIN RSET MIN
or
RSET RPM
MAN RSET PROPBD2
or
GAIN 2
RATE2MIN RSET2MIN
or
RSET2RPM
CYC SEC
or
CYC SX3
CYC2 SEC
or
CYC2 SX3
SECURITY LOCKOUT AUTO MAN SP SEL RUN HOLD PVEUVALx
GAINVALx
TUNINGL2
PROP3BD
or GAIN3
GAINVALn RATE3MIN RSET3MIN
or
RSET3RPM
MANRSET3 PROPBD4
or
GAIN 4
RATE4MIN RSET4MIN
or
RSET4RPM
CYC3 SEC
or
CYC3 SX3
CYC4 SEC
or
CYC4 SX3
PVEUVALx GAINVALx
SP RAMP
SP RAMP TIME MIN FINAL SP SP RATE EU/HR UP EU/HR DN EUHRUP2 EUHRDN2
SP PROG STRT SEG END SEG RAMPUNIT RECYCLES SOAK DEV PROG END STATE
ToBEGIN
SEGxRAMP
or
SEGxRATE
*
SEGx SP*
* x = 1 to 12. Program concludes after segment 12
