Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 37
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
IN1 HI
Input 1 High Range Value
(Linear Inputs only)
–999. to 9999. floating
(in engineering units)
1000
IN1 LO
Input 1 Low Range Value
(Linear Inputs only)
–999. to 9999. floating
(in engineering units)
0
RATIO 1
Input 1 Ratio –20.00 to 20.00
(floats to 3 decimal places)
1.000
BIAS IN1
Input 1 Bias –999. to 9999.
(in engineering units)
0
FILTER 1
Input 1 Filter 0 to 120 seconds 0
BURNOUT1
Burnout Protection NONE DOWN
UP NO_FS
NONE
EMISSIV1
Emissivity 0.01 to 1.00 0.00
3.10 Input 2 Parameters Set Up Group
Table 3-9 Input 2 Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
IN2 TYPE
Input 2 Actuation Type
For Input Range
Minimum and Maximum
see Appendix E
DISABL NM90 L 500 PT
B TC NIC TC RAD RH
E TC H R TC RAD RI
E TC L S TC 0-20mA
J TC H T TC H 4-20mA
J TC L T TC L 0-10mV
K TC H W TC H 0-50mV
K TC L W TC L 0-5 V
NNM H 100 PT 1-5 V
NNM L 100 LO 0-10 V
NM90 H 200 PT SLIDEW
0-10mV
