Honeywell UDC3300 User Manual

Installation
5/00 UDC3300 Expanded Model: DC330E User Manual 11
Time Proportional
If the load current is less than the minimum rated value of 20 mA, there may be a residual voltage
across both ends of the load even if the relay is turned off. Use a dummy resistor as shown to
counteract this. The total current through the resistor and the load current must exceed 20 mA.
1
2
3
Alarm #2 not available with Time Proportional Duplex or Three Position Step Control or Position
Proportional control.
Solid State relays are rated at 0.5 amps. Customer should size fuses accordingly. Use Fast Blo
fuses only.
Electromechanical relays are rated at 5 Amps @120 Vac or 30 Vdc and 2.5 Amps at 240 Vac.
Customer should size fuses accordingly. Use Fast Blo fuses only.
WARNING: Only connect Vac to solid
state relays.
4
Alarm
Relay#1
Output
Relay#1
To terminal
7 or 9
Output
Relay#2
AC Load
Supply
Power
Relay Load
Dummy Resistor
N.O.
N.O.
AC Load
Supply
Power
Relay Load
Dummy Resistor 1
1
3
3
2
1
2
3
4
5
6
7
8
9
N.O.
N.C.
AC Load
Supply
Power
Alarm Relay #1 Load
4
Alarm
2
2
1
Figure 2-8 Solid State (SS) Relay Output — Model DC33-X-AA-XX
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
AC
–
+
Solid State
Relay
+
+
–
–
Green
White
Black
Output 1
1
Output 2
L2/N
L1
HOT
LOAD
1
External solid
state relays are
rated at 15 amps
@25°C derated
to 10 amps at
55°C. Customer
should size fuses
accordingly. Use
Fast Blo fuses
only.
Figure 2-9 10-amp SS External Relay Output — Model DC330X-SS-XX
