Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 23
3.3 Loop 1 Tuning Parameters Set Up Group
Table 3-2 Loop 1 Tuning Group Function Prompts
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
PROP BD
or
GAIN
Proportional Band
or
Gain
0.1 to 9999%
0.001 to 1000
- -
1.000
or
GAINVALn
Or
Gain Value being used by
Gain Scheduling when
enabled
Read Only - -
RATE MIN
Rate in Minutes 0.00 to 10.00 minutes 0.00
RSET MIN
or
RSET RPM
Reset in minutes/repeat
or
Reset in repeats/minute
0.02 to 50.00 1.00
- -
MAN RSET
Manual Reset –100 to 100% output 0
PROPBD2
or
GAIN 2
Proportional Band 2
or
Gain 2
0.1 to 9999%
0.001 to 1000
- -
1.000
RATE2MIN
Rate 2 in Minutes 0.00 to 10.00 minutes 0.00
RSET2MIN
or
RSET2RPM
Reset 2 in minutes/repeat
or
Reset 2 in repeats/minute
0.02 to 50.00 1.00
- -
CYC SEC
or
CYC SX3
Cycle Time (Heat) 1 to 120 20
CYC2 SEC
or
CYC2 SX3
Cycle Time (Cool) 1 to 120 20
SECURITY
Security Code 0 to 4095 0
