Configuration
44 UDC3300 Expanded Model: DC330E User Manual 5/00
3.14 Options Set Up Group
Table 3-13 Options Group Function Prompt
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
AUX OUT
or
CUR OUT2
Auxiliary Output One
Loop Selection OR
Auxiliary Output Two
Loops/Cascade Selection
DISABL OUTPUT PV 2
INP 1 SP DEV 2
INP 2 LSP 1 OUTPT2
INP 3 IN AL1 SP L2
CBOUT IN AL2 LSP1 2
PV DEV CBOUT2
DISABL
4mA VAL
Auxiliary Output Low
Scaling Factor
Low scale value to represent 4 mA.
Value in % for output, all others in
engineering units.
0.0
20mA VAL
Auxiliary Output High
Scaling Factor
High scale value to represent
20 mA.
Value in % for output, all others in
engineering units.
0
DIG IN 1
Digital Input 1 Selections
NOTE: DIG IN 1 applies
to Loop 1 when 2 LOOPS
or CASCAD is configured.
NONE ToAout
HealthWatch
TO MAN TIMER RESETT1
TO LSP AM STA RESETT2
TO 2SP ToTUNE RESETT3
TO 3SP Spinit R ALL T
TO DIR TRACK1 RESETC1
ToHOLD TRACK2 RESETC2
ToPID2 ToOUT2 RESETC3
PV 2IN TO RSP R ALL C
PV 3IN D L1/2 R ALL TC
RERUN RST FB
TO RUN ToPURG
ToBEGN LoFIRE
STOP I MAN LT
MAN FS REStot
ToLOCK
NONE
DIG1 COM
Digital Input 1
Combinations
DISABL +DISAT
+PID2 +ToSP1
+ToDIR +RUN
+ToSP2
DISABL
DIG IN 2
Digital 2 Input Selections Same as DIG IN 1
NOTE: DIG IN 2 applies to Loop 2
when 2 LOOPS or CASCAD is
configured.
NONE
DIG2 COM
Digital Input 2
Combinations
Same as DIG1 COM DISABL
