Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 35
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
OUT2 ALG
Loop 2 Output Algorithm NONE
TIME
CURRNT
CUR D
CUR TI
TI CUR
CURRNT
RLYSTATE
Digital Output State at 0%
Output
1OF2OF (Output relays 1 and 2
are both de-
energized)
1ON2OF (Output relay 1 is
energized, output
relay 2 is de-
energized)
1OF2ON (Output relay 1 is de-
energized, output
relay 2 is energized)
1ON2ON (Output relays 1 and 2
are both energized)
1OF2ON
RLY TYPE
Relay Cycle Time
Increments
MECHAN(Cycle time in one
second increments)
SOL ST (Cycle time in 1/3
second increments: 1
= .33 seconds,
120 = 40 seconds)
MECHAN
