Honeywell UDC3300 User Manual

Configuration
48 UDC3300 Expanded Model: DC330E User Manual 5/00
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
A1S1TYPE
continued
Alarm 1, Setpoint 1 Type
continued
Health Watch
TIMER 1
TIMER 2
TIMER 3
COUNT 1
COUNT 2
COUNT 3
A1S2TYPE
Alarm 1, Setpoint 2 Type Same as A1S1TYPE NONE
A2S1TYPE
Alarm 2, Setpoint 1 Type Same as A1S1TYPE NONE
A2S2TYPE
Alarm 2, Setpoint 2 Type Same as A1S1TYPE NONE
A1S1 H L
Alarm 1, Setpoint 1 State LOW
HIGH
HIGH
A1S1 EV
SP Programming Event
Alarm State for Alarm 1,
Setpoint 1
BEGIN
END
- -
A1S2 H L
Alarm 2, Setpoint 1 State LOW
HIGH
LOW
A1S2 EV
SP Programming Event
Alarm State for Alarm 1,
Setpoint 2
BEGIN
END
- -
A2S1 H L
Alarm 21, Setpoint 1 State LOW
HIGH
HIGH
A2S1 EV
SP Programming Event
Alarm State for Alarm 2,
Setpoint 1
BEGIN
END
- -
A2S2 H L
Alarm 2, Setpoint 2 State LOW
HIGH
LOW
A2S2 EV
SP Programming Event
Alarm State for Alarm 2,
Setpoint 2
BEGIN
END
- -
AL HYST
Alarm Hysteresis 0.0 to 100.0 % of output or span,
as appropriate
0.1
ALM OUT1*
Latching Alarm for Output
1
NO LAT
LATCH
NO LAT
