Configuration
28 UDC3300 Expanded Model: DC330E User Manual 5/00
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
RAMPUNIT
Engineering Units for
Ramp Segments
TIME (hours.minutes)
EU/MIN(engineering
units/minute)
EU/HR(engineering units/hour)
TIME
RECYCLES
Number of Program
Recycles
0 to 99 recycles ––
SOAK DEV
Guaranteed Soak
Deviation Value
0 to 99
The number selected will be the
PV value (in engineering units)
above or below the setpoint
outside of which the timer halts.
––
PROG END
Program Termination State LASTSP (Hold at last setpoint in
the program)
F SAFE (Manual mode/Failsafe
output)
––
STATE
Program State at Program
End
DISABL
HOLD
––
KEYRESET
Reset SP Program DISABL
TOBEGN
RERUN
DISABL
HOT START
Hot Start DISABL
ENAB
DISABL
SEG1RAMP or
SEG1RATE
Segment #1 Ramp Time or
Segment #1 Ramp Rate
0-99 hours.0-59 minutes
Engineering units/minute or
Engineering units/hour
Select TIME, EU/MIN, or
EU/HR at prompt RAMPUNIT.
All ramps will use the same
selection.
––
SEG2 SP
Segment #2 Soak Setpoint
Value
Within the Setpoint limits ––
SEG2TIME
Segment #2 Soak Duration 0-99 hours.0-59 minutes ––
