Honeywell UDC3300 User Manual

Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 41
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
OUT RATE
Output Change Rate ENABLE
DISABL
Does not apply to 3 Position Step
Control algorithm.
DISABL
PCT/M UP
Output Rate Up Value 0 to 9999 % per minute 0
PCT/M DN
Output Rate Down Value 0 to 9999 % per minute 0
OUTHiLIM
High Output Limit –5.0 to 105 % of output 100
OUTLoLIM
Low Output Limit –5.0 to 105 % of output 0.0
I Hi LIM
High Reset Limit Within the range of the output
limits
100.0
I Lo LIM
Low Reset Limit Within the range of the output
limits
0.0
DROPOFF
Controller Dropoff Value –5 to 105 % of output 0
DEADBAND
Output Relay Deadband Time Duplex:
–5.0 to 25.0 %
On/Off Duplex:
0.0 to 25.0 %
Position Prop. and 3P Step:
0.5 to 5.0 %
1.0
OUT HYST
Output Relay Hysteresis 0.0 to 100.0 % of PV Span for
On/Off control.
0.5
FAILMODE
Failsafe Mode NO LAT
LATCH
NO LAT
FAILSAFE
Failsafe Output Value for
all outputs except 3P Step
Set within the range of the output
limits. 0 to 100 %
0.0
Failsafe Output Value for
3P Step
0 PCT (motor to closed position)
100PCT (motor to open position)
- -
SW FAIL
PDMR/Position Propor-
tional motor position when
slidewire fails.
0 PCT (motor to closed position)
100PCT (motor to open position)
MAN OUT
Power-up Preset Output
for Manual Output
Within the range of output limits - -
AUTO OUT
Power-up Preset Output
for Automatic Output
Within the range of output limits - -
PBorGAIN
Proportional Band or Gain
Units
PB PCT
GAIN
GAIN
MINorRPM
Reset Units RPM
MIN
MIN
