Honeywell Ultrakey Lite User Manual

VideoBloX Mode
18
5 VideoBloX Mode
This chapter describes how to connect, configure and operate the Ultrakey Lite when it is used
with VideoBloX.
Overview
Ultrakey Lite can control the remote VideoBloX via either the serial port or the Ethernet.
Connection
To connect Ultrakey Lite with VideoBloX by the serial port, refer to the following figure:
Figure 5-1 Connecting VideoBloX by Serial Port
Ultrakey Lite
Network
cable
Serial Port
RJ45 to DB9M
Connector
VideoBlox (Old)
Ultrakey Lite
Network
cable
Serial Port
VideoBlox (New)
To connect Ultrakey Lite with VideoBloX by Ethernet, refer to the following figure:
