Introduction
4
Specifications
Parameter Value
Power Requirements 10.8 to 13.2 VDC @ 1 Ampere (A) or POE (48VDC, Class 3)
1×Ethernet (10Base-T, 100Base-TX) RJ45 With LED
Connector Types
1×RS232/422/485 RJ45 With LED
Type: STN, Positive Image
Backlight: Blue-White
LCD
Characters: 122×32 Dots
Type: A
USB
Version: USB1.1 (For USB PC Keyboard)
Type: CR2032
Battery
Voltage: 3V
Compliance EN55022 for radiated and conducted emissions
Dimensions: 408mm (L) × 215 mm (W) × 105mm (H)
Gross Weight: 3.2 kg
Mechanical
Cover material: ABS+PC (cool gray)
Operating Temperature: -10 to +55 deg C
Storage Temperature: -40 to +75 deg C
Environment
Humidity: 0 to 95% RH (non-condensing)
