Standalone Mode
34
HRHD DVR
Keyboard Setup
The HRHD DVR function setup is just like the FUSION DVR function setup except that the
HRHD type must be selected.
Operations
DVR selection
Pressing a number followed by the DVR key selects a DVR to control.
Number entry (for entering passwords)
To enter numbers, press and hold the Alt key and then press the number keys.
DVR menus
Press F1 to bring up the password screen. Press and hold the Alt key, and enter the password.
Then press Ent to start the access to the DVR set-up menus.
Navigation between these menu items is achieved by using the function keys indicated in the
table below:
Press… To…
Slider_Up or F2 Move up
Slider_Down or F7 Move down
Slider_Left or F6 Move left
Slider_Right or F8 Move right
F1
Exit the current menu. (If the user presses F1
when in the ‘Set-up screen’, the DVR exits
the menus and returns to normal operation.)
or enter the menu
Ent select an option
Picture control
The following table indicates the keys used for picture control:
Key Function
Split Display
Seq Sequence
F10 Freeze
Press Split to select the next display setting (in the cycle of ‘4x4’, ‘3x3’, ‘2x2’ and ‘PIP’).
Use the Slider_Left and Slider_Right keys to cycle through the other cameras when
displaying 2x2 and 3x3 displays.
The screen layout of the multi-camera displays can be set by pressing Ent, then Slider_Up,
Slider_Down, Slider_Left or Slider_Right keys to select an active camera (highlight box
displayed). Then press one or two of the number keys (to enter a legal camera number)
followed by the Camera key to select that number camera to be displayed in that cameo.
