Honeywell Ultrakey Lite User Manual

Maxpro Mode
22
6 Maxpro Mode
This chapter describes how to connect, configure and operate the Ultrakey Lite when it is used
with Maxpro-Net.
Connection
Ultrakey Lite can control the remote Maxpro via either the serial port or the Ethernet.
To connect Ultrakey Lite with Maxpro by the serial port, refer to the following figures, normally,
you can select RS232 by menu to connect with Maxpro directly. (
Figure 6-1).
When Ultrakey Lite is remote with Maxpro, you can select RS422 by menu to connect with
Maxpro indirectly. (
Figure 6-2)
Figure 6-1 Connecting Maxpro by Serial Port (RS232 for Ultrakey Lite)
