HEATING SYSTEM CONTROL
20 4 213 563 / 03
Overview of control elements
Page 1/3 Page 2/3 Page 3/3
Emission
- Selection heat generator
- Remaining run time
- Output limitation
- Information area
Analysis
- Selection heat generator, heating cir-
cuit, hot water
- Selection duration
- Diagram display
Visualisation
- For solar collector systems
Heating
circuits
- Desired room temperature
- Basic program selection
- Day program selection
- Switching cycles room temperature
Hot water
- Desired HW temperature
- Basic program selection
- Day program selection
- Switching cycles hot water
Programs
- Selection heating circuit/hot water
- Detailed selection heating circuit/
hot water
- Adapting week programs
- Adapting day programs
System
Display of the next due
maintenance/cleaning/service
Info
- Information area selection
- Detailed selection heat generator, hea-
ting circuit, hot water, solar, etc.
- Information area
User level
- User level PIN entry
Service
Menu item only for heating specialist
Manual
mode
- Selection heat generator/heating
circuit
- Detailed selection
- Cooling operation/OFF/heating
operation
- Information
Presentation
- Language
- Colour scheme
- Start screen
- Backlighting
- Duration until standby
- Display until standby
- Authorisation
- Conguration analysis
Commissioning
Menu item only for heating specialist
Update
Menu item only for heating specialist
Power station
Inuence of weather forecast on the
heating. The function is only active
with remote connection.
Functions might not be availa
-
ble for selection, depending on
the version of your operating
element.
Information
- Information area selection
- Detailed selection heat generator, hea-
ting circuit, hot water
- Information area
Hot water
- Desired HW temperature
- Basic program selection
- Day program selection
- Switching cycles hot water
- Selection heating circuit
- Selection joint operation
active heating
circuit
- Room temperature setting
- Day program selection
- Display active switching cycles
Room temperature/
day program
- Basic program selection
Basic program
Main menu
