Hoval Uno-3 - Main Menu View 3

HEATING SYSTEM CONTROL
60 4 213 563 / 03
5.12.3 Main menu view 3
2
7
8
3
1
11
9
10
4
5
6
No. Designation Function
1 Update Menu item only for heating specialist
2 Commissioning Menu item only for heating specialist
3 Power station Inuence of weather forecast on heating. Selection of the heating or hot
water circuit to be edited only functions if.
4 Ventilation Only active in connection with a residential ventilation system. (comfort
plus)
5 Heating and cooling characte-
ristic (optional: for heat pumps
only)
The characteristic curves are normally set by the specialist during com-
missioning of the heating system. They describe the ratio between the
installation ow temperature and the current outdoor temperature.
When using a room control module, the characteristic curves are auto-
matically optimised by the TopTronic
®
E.
6 Energy Manager The Energy Manager visualises the power generation and is only active
in connection with a photovoltaic system.
7 Position in the menu Name of the currently selected menu item
8 Time of day Displays the current time.
9 Page in the main menu Display of the active main menu page (1)
10 Scroll Arrow (
) for navigating from main menu page 3 to main menu page 2
11 Back Used as a button (
) for returning to the start screen.
Individual menu items are active or inactive
depending on the type of control module.
