774 213 563 / 03
ALARM MESSAGES
7.2 Control related alarm messages
You can deal with the alarm messages listed below yourself, with the help of the description. If an alarm
message appears on your TopTronic
®
E control module that is not listed below, please contact Hoval Cus
tomer Service.
7.3 Plant-related alarm messages
Malfunction Inspection/cause Remedy
Oil boiler
does not start
- Is power supply present? - Check fuses. Switch on the main/emergency
switch or plug in the power plug.
- Is the red fault indicator lit? - Press the reset button on the control panel
- Call Hoval customer service
- Oil level check - Top up oil
- Is the burner connector plugged in? - Plug in the connector
- Has the safety temperature limiter tripped? - Call Hoval customer service
Gas burner is not
running
- Is power supply present? - Check fuses. Switch on the main/emergency
switch or plug in the power plug.
- Is the gas cock open? - Open
- Is the fault lamp lit? - Press the fault clearance key
- Notify the oil burner service
- Is gas available? - Ask the gas board
- Is the burner connector plugged in? - Plug in the connector
- Has the safety temperature limiter tripped? - Loosen the screws and unlock by pressing
the button
Radiators or un-
deroor heating
do not become
warm
- Are the slide valves in the heating ow and
return open?
- Open slide valve
- Is the main switch set incorrectly? - Main switch ON
- Is the operating mode switch set incorrect-
ly?
- Set
- Have the switching times of the TopTronic
®
E
been set correctly?
- Check using operating instructions for the
heating control
- Check the setting on the temperature adjuster - Increase setting
- Check the water level / pressure - Too low - notify installer
- Are the radiator valves open? - Open
- The heating circulating pump is not running - Open the locking screw, and turn end of
shaft vigorously with a screwdriver until the-
re is no longer resistance
- Mixer does not open automatically - Open by hand; call Customer Service
