HEATING SYSTEM CONTROL
58 4 213 563 / 03
5.12 Other operating elements
5.12.1 Main menu view 1
2
5
7
8
1
4
11
3
6
9
10
No. Designation Function
1 Emission metering For heating specialist: setting the emission output limitation
2 Analysis See 5.12.12 page 69
3 Visualisation For heating specialist: not available with all heat generators
4 Heating circuits Display and editing possibility of the selected heating circuit. Depending
on the structure of the system, it is possible to select between one or
more heating circuits. Information about the active operating and day pro-
gram (5.12.7 page 64)
5 Hot water Display and editing possibility of the selected hot water circuit. Depen-
ding on the structure of the system, it is also possible to select between
one or more domestic hot water circuits in the hot water area. Specica-
tions regarding an active operating and day program with adapted hot
water temperature (5.11.1 page 51)
6 Programs Menu item for adapting week and day programs in the selected heating
or hot water circuit (5.12.6 page 63)
7 Position in the menu Name of the currently selected menu item
8 Time of day Displays the current time.
9 Page in the main menu Display of the active main menu page (1)
10 Scroll Arrow (
) for navigating from main menu page 1 to main menu page 2
11 Back Used as a button (
) for returning to the start screen.
Individual menu items are active or inactive
depending on the type of control module.
