Hoval Uno-3 - Heating Circuit

HEATING SYSTEM CONTROL
64 4 213 563 / 03
5.12.7 Heating circuit
(Main menu / Heating circ.)
1
8 7
2
3
4
5
6
9
No. Designation Function
1 Active heating circuit Display of the heating circuit to be edited. Changed settings are exclusi-
vely accepted in the selected heating circuit. Use the down arrow (
) to
change the heating circuit.
2 Desired temperature Displays the temperature programmed in the switching cycle. The tem-
perature can be changed in the active switching cycle using plus (
) and
minus ( ).
3 Basic program Selection of the basic program. Use the down arrow (
) to select a new
program for editing.
4 Day program Use the down arrow (
) to change the day program.
5 Switching cycles Graphical display of the currently selected day program with all time
cycles and corresponding temperature specications. The time period
marked in yellow shows the currently active cycle in which the desired
temperature can be changed with plus (
) and minus ( ).
6 Time of day Displays the current time.
7 OK Save (
) the changes in the selected heating circuit and return to the
previous screen
8 Help No function is available at present
9 Back Used as a button (
) for returning to the main menu.
Temporary settings “Only for today” are not
possible in the “Heating circ.” menu item.
