HP 54710A - Page 139

Text Y Values
Text Y values files are identical to the text verbose files, except the header
information is deleted from the front of the file. Figure 8-5 shows an example
of the text Y values format. Text Y values files also have a .TXT file extension.
Figure 8-5
5.657E-001
6.433E-001
5.974E-001
1.864E-001
8.05E-002
-3.147E-001
-3.057E-001
-4.77E-002
5.280E-001
6.296E-001
6.296E-001
2.297E-001
1.259E-001
-3.147E-001
-3.147E-001
-9.40E-002
Text Y values format
X Data:
4.757E-002
5.117E-002
1.885E-002
-5.07E-003
-2.916E-002
-3.979E-002
-3.649E-002
5.82E-003
2.880E-002
4.727E-002
4.230E-002
2.318E-002
-3.91E-003
-2.568E-002
-3.931E-002
-2.178E-002
Y Data:
4.757E-002
5.117E-002
1.885E-002
-5.07E-003
-2.916E-002
-3.979E-002
-3.649E-002
5.82E-003
2.880E-002
4.727E-002
4.230E-002
Text Y values, versus waveform
Disk Menu
File Format
8–18
