To edit a polygon
1
Set the coordinate system in the Scale menu.
2
Select the polygon number with the polygon softkey in the edit mask menu.
3
Press the
Edit polygon
softkey.
4
Press the
Point
softkey.
5
Use the knob or keypad to select the point on the polygon you wish to edit.
The scope will not let you select a point that is not defined.
6
Edit the selected point.
To delete the selected point, press the delete softkey. To insert a point or
move a point, use the X and Y softkeys to move the cursor to the desired
location. Then press the Insert softkey to insert a new point, or press the
Move softkey to move the selected point to the new location.
Mask Menu
Edit Mask
23–16
