Internal AM Rate
Function Group
Menu Map
Description
Programming Codes
See Also
IIV1OD)
4
This softkey (Option 002 only) lets you set the AM rate for
internally-generated AM. Use the numeric entry keys, arrow keys,
or rotary knob to change the rate. The synthesizer accepts values
from 1 Hz to 1 MHz, however it is specified to 1 MHz only for a sine
waveform. Refer to the specifications. The factory preset rate is
100
kHz.
SCPI: AM:INTernal:FREQuency
<num>[<freq
suffix>]
1
MAXimum
I
MINimum
Analyzer: NONE
(MOD_),
also see “AM” and “Modulation”.
Internal AM Waveform Noise
Function Group
Menu Map
Description
Programming Codes
See Also
4
This softkey (Option 002 only) lets you set the AM waveform to
noise (white noise AM rate;
gaussian
distribution centered around
AM depth) for internally-generated AM. An asterisk next to the key
label indicates that this feature is active. The factory preset default
is sine wave.
SCPI: AM:INTernal:FUNCtion NOISe
Analyzer: NONE
(MOD_),
also see “AM” and “Modulation”.
l-2
Operating and Programming Reference
HP 8360
User’s Handbook
