HP 8360 - Rear Panel HP-IB Switch; Factory-Set HP-IB Addresses

HP-IB
LANG ADDRESS
Figure 3-2. Rear Panel HP-IB Switch
HP-IB Address
In certain applications, the synthesizer acts as a controller for a
Selection
power meter and a printer.
Because of this, the address menu
provides access not only to the synthesizer’s HP-IB address, but also
to the address at which the synthesizer expects to see a power meter,
and the address at which the synthesizer expects to see a printer.
(See Table 3-2 for factory-set addresses.)
Table 3-2. Factory-Set HP-IB Addresses
Instrument HP-IB Address
(Decimal)
Synthesizer
19
Power Meter
13
Printer
01
Specifications
INSTALLATION 3-7
