Internal FM Rate
Internal FM Deviation
Function Group
Menu Map
Description
Programming Codes
See Also
4
This softkey (Option 002 only) lets you set the FM deviation for
internally-generated FM. Use the numeric entry keys, arrow keys, or
rotary knob to change the value of the deviation. The synthesizer
accepts values from 1 Hz to 10 MHz. The factory preset deviation is
1 MHz.
SCPI: FM[:DEViation] <num>[freq suffix]]MAXimum(MINimum
Analyzer: NONE
(MOD_), also see “AM” and “Modulation”.
Internal FM Rate
Function Group
Menu Map
Description
Programming Codes
See Also
INIOD)
4
This softkey (Option 002 only) lets you set the FM rate for
internally-generated FM. Use the numeric entry keys, arrow keys, or
rotary knob to change the value of the rate. The synthesizer accepts
values from 1 Hz to 1 MHz, however it is specified to 1 MHz only for
a sine waveform. Refer to the specifications. The factory preset rate
is 1 MHz (note that the synthesizer also presets to a sine waveform).
SCPI: FM:INTernal:FREQuency <num>[freq suffix]]MAXimum]MINimum
Analyzer: NONE
(MODI, also see “FM” and “Modulation”.
HP 8360
User’s Handbook
Operating and Programming Reference I-5
