HP 8360 - Modulation; Pulse

Modulation
Pulse
Pulse modulation specifications apply for output frequencies 400
MHz and above.
On/Off Ratio”
Rise/Fall Times
Minimum Width
Internally Leveled
Search Mode
Output Frequencies < 2.0 GHz
Output Frequencies 2 2.0 GHz
ALC Off Mode
Output Frequencies < 2.0 GHz
Output Frequencies 2 2.0 GHz
Minimum Repetition Frequency
Internally leveled
Search Mode
ALC Off Mode
Level Accuracy
(dB, relative to CW level)
Widths 2 1 ps
Widths < 1 ps (Search Mode)
Video Feedthrough
Output Frequencies < 2.0 GHz
Power Levels 2 10 dBm
Power Levels > 10 dBm
Output Frequencies > 2.0 GHz
HP 83620A/22A/30A
HP 83623A/24A/40A/50A
Overshoot, Ringing
Delay12
Output Frequencies < 2.0 GHz
Output Frequencies > 2.0 GHz
Compression
Output Frequencies < 2.0 GHz
Output Frequencies > 2.0 GHz
Standard
Option 006
80 dB 80 dB
25 ns 10 ns
1 PS
50 ns
50 ns
1 P
50 ns
15 ns
50 ns
50 ns
50 ns
15 ns
10 Hz
10 Hz
DC
DC
DC
DC
f0.3
f0.5, typical
f0.3
f0.5, typical
2%
5%
2%
5%
0.1%
1%
15%, typical
1%
1%
lo%, typical
80 ns, typical
80 ns, typical
80 ns, typical
60 ns, typical
&lo ns, typical f10 ns, typical
f10 ns, typical f5 ns, typical
I1 In the HP 83623A/24A, specification applies at ALC levels 0 dBm and above,
and over the 20 to 55’C temperature range. Specification degrades 5 dB below 20°C,
and 1 dB per dB below ALC level 0 dBm in those models.
I2 Option 002 adds 30 ns delay and zt5 ns pulse compression for external pulse inputs.
HP 8380
User’s Handbook
Change B 5-5
