Sets and queries an array of up to 801 frequency-correction
pairs. This correction information is used to create a correction
array that can be added to the internal calibration array. The
correction entered is at the associated frequency. Frequencies in
between frequency-correction pair values are determined by linear
interpolation. If a value of START or STOP frequency is specified
that is outside the limits of the specified frequencies, the correction
applied at those points is 0 dB. After
*RST,
returns a
MinFreq,
0
DB ,
MaxFreq,
0 DB response.
l
CORRection:SOURce[i]
ARRaylFLATness
l
CORRection:
SOURce
cil?
Sets and queries the source of correction.
l CORRection:FLATness:POINts?
[MAXimumlMINimum]
Returns the number of frequency-correction pairs entered using the
CORR:FLAT
command. After
*RST,
the value is 2.
l CORRection[:STATe] ONlOFFlllO
l
CORRect ion
[
:
STATe]
?
Sets and queries the switch on the users ALC correction system.
The *RST value is OFF.
l
DIAGnost
its
:
ABUS?
<num>
Reads the analog bus node number and returns the number of
millivolts:
l DIAGnostics:ABUS:AVERage
<num>
l DIAGnostics:ABUS:AVERage?
Sets and queries the number of ADC averages to use during the read
ADC query. After
*RST,
the value is 1.
l DIAGnostics:ABUS:STATus?
Queries the status of the prior ADC reading. The response is a single
byte that is bit-encoded to mean:
Bit 0
Set to 1, if ADC timed out (hardware fault)
Bit 1
Set to 1, if reading was unsettled.
Bit 2
Set to 1, if out of range occurred.
l DIAGnostics:INSTrument:PMETer:ADDRess
<num>
l DIAGnostics:INSTrument:PMETer:ADDRess?
Sets and queries the HP-IB address to use for the power meter during
synthesizer calibration routines. Allowable values are 0 through 31.
‘RST
or power on does not effect this value. Default is 13. It is
defaulted only when memory is initialized.
HP 8360
User’s Handbook
Operating and Programming Reference
S-31
