Up/Down
Power
Function Group
POWER
Menu Map
5
Description
This
softkey
activates the power step size function. It can be set
from 0.01 to 20 dB. In this mode, power is stepped by the up/down
arrow keys. An asterisk next to the key label indicates this feature is
active.
Programming Codes
SCPI:
POWer:STEP[:INC
rement]
<num>[DB]
or
MAXimumlMINimum
POWer:STEP:AUTO
ONlOFFlllO
Analyzer: SP or SHPL and UP or DOWN
See Also
Up/Dn
Size
CW,
Up/Dn
Size Swept
“Programming Typical Measurements,” in Chapter 1.
Up/b
Size
CV
Function Group
FREQUENCY
Menu Map
2
Description
This
softkey
lets you set the frequency step size for the CW
frequency mode. The step size may be set from 1 Hz to 10
GHz. The factory preset size is 100 MHz. CW frequency is
incremented/decremented by pressing the up/down arrow keys.
If an underline cursor appears under a digit in the entry display, then
the value will be modified by the up/down arrow keys or the rotary
knob. The increment/decrement size in this case is the underlined
digit by the power of 10.
If the up/down function is on (asterisk next to key label) and the
cursor is not under one of the active entry area digits, then frequency
value is changed by the up/down size using either the up/down arrow
keys or the rotary knob.
U-2
Operating and Programming Reference
HP 8360
User’s Handbook
