8-14 ES User’s Guide
Hardkey/Softkey Reference
C
C
Softkey in the open menu. Allows you to modify the C
0
characteristic of
the open calibration standard in your calibration kit.
See “Calibration Kits” on page 6-23 for more information.
Access Keys:
Softkey in the open menu. Allows you to modify the C
1
characteristic of
the open calibration standard in your calibration kit.
See “Calibration Kits” on page 6-23 for more information.
Access Keys:
Softkey in the open menu. Allows you to modify the C
2
characteristic of
the open calibration standard in your calibration kit.
See “Calibration Kits” on page 6-23 for more information.
Access Keys:
Softkey in the open menu. Allows you to modify the C
3
characteristic of
the open calibration standard in your calibration kit.
See “Calibration Kits” on page 6-23 for more information.
Access Keys:
(Option 100 only) Softkey in the menu. Sets up the analyzer
for fault location and SRL measurements. See your Option 100 User's
Guide Supplement for information.
Hardkey in the CONFIGURE area. Displays the calibration menu
options for the current measurement mode.
See Chapter 6 for information on calibrating the analyzer.
CAL
CAL
CAL
CAL
BEGIN
CAL
