ES User’s Guide 8-17
Hardkey/Softkey Reference
C
Softkey in the more display menu. Allows you to customize the colors
on an external VGA monitor connected to the rear panel VIDEO OUT
connector.
See “Using an External VGA Monitor” on page 4-87 for more
information.
Access Keys:
Softkey in the add login user menu. Displays a dialog box for
confirming a password to be added to the access list of your analyzer.
See The LAN Interface User’s Guide Supplement for more information.
Access Keys:
Softkey in the select disk menu. Displays the menu to modify the
memory allocation for the internal volatile RAM disk.
Access Keys:
Softkey in the IBASIC menu. Restarts a program that has been
paused.
See the HP Instrument BASIC User's Handbook and Supplement for
more information on using IBASIC.
Access Keys:
Softkey in the trigger menu. In the continuous mode, the analyzer is
triggered continuously, beginning its next sweep at the conclusion of
the current sweep. Continuous is the default trigger mode.
Access Keys:
Softkey in the mixer menu and measurement menus, for measuring
frequency translating devices. Selects a broadband internal
transmission measurement.
See “Measuring Conversion Loss” on page 3-61 for more information.
Access Keys: or or
DISPLAY
SYSTEM OPTIONS
SAVE RECALL
SYSTEM OPTIONS
MENU
BEGIN
MEAS 1
MEAS 2
