8-38 ES User’s Guide
Hardkey/Softkey Reference
H
Softkey in the more CRT adjust menu. Adjusts the CRT timing for
using the analyzer with an external monitor. Also affects the network
analyzer's internal CRT. Default setting is 3.68 µsec. This setting is not
affected by an instrument preset.
See “Using an External VGA Monitor” on page 4-87 for more
information.
Access Keys:
Softkey in the more CRT adjust menu. Adjusts the CRT timing for
using the analyzer with an external monitor. Also affects the network
analyzer's internal CRT. Default setting is 31.68 µsec. This setting is
not affected by an instrument preset.
See “Using an External VGA Monitor” on page 4-87 for more
information.
Access Keys:
Softkey in the CRT adjust menu. Changes the horizontal positioning of
the display on both the internal CRT and an external monitor. Accepts
whole number values from 1 to 100, with 1 representing as far left as
possible and with 100 representing as far right as possible. The default
value set at the factory (and obtained by pressing Restore Defaults) is
73. This setting is not affected by an instrument preset.
See “Using an External VGA Monitor” on page 4-87 for more
information on using an external display.
Access Keys:
Softkey in the file format menu. Select this key only if you are saving
instrument states that are to be used in older model ("A" or "B")
analyzers.
See “Saving and Recalling Measurement Results” on page 4-55 for
more information.
Access Keys:
SYSTEM OPTIONS
SYSTEM OPTIONS
SYSTEM OPTIONS
SAVE RECALL
